Tire Valves & Valve Tools
Large-Bore Tire Valves & Accessories
Large-bore valves and accessories form a separate family for compatible heavy-service wheel systems. The catalogue lists valve bodies and related components.
Key Specifications
- Series
- Large-Bore Tire Valves & Accessories
- Listed configurations
- 24
- Selection
- Valve type / connection · Dimensions (mm / in) · Angle / selection
- Catalogue reference
- Tire Service Products, pp. 51
Product Details
Review large bore tire valve specifications and compare the listed models. Match the bore system, mounting thread and lettered dimensions. Confirm whether the selected row is a complete valve or an accessory. The specification table lists the catalogue models and ordering configurations on this page. Include the selected model, configuration and quantity in your quotation request.
Model Differences
- TRJ650: Single-bend swivel.
- J1076C: Screw-on inner tube valve.
- TRSP2: Tubeless spud.
Applications
Typical application
Heavy-equipment tire-service parts supply.
Distributor and workshop orders
Specify the model mix and quantity required for your stock range. Include destination and packaging requirements so the quotation can address the intended order.
Models & Specifications
Compare specifications and select the models or size configurations for your quotation.
Swipe the table to compare all dimensions.
| Model / SKU | Valve type / connection | Dimensions (mm / in) | Angle / selection | Quantity (pcs) | |
|---|---|---|---|---|---|
| TRJ650 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 3-1/8 in / 79.4 mm | 100° | ||
| TRJ651 | Single-bend swivelA and B follow catalogue drawing. | A: 1-1/4 in / 32 mm; B: 4-11/16 in / 119 mm | 90° | ||
| TRJ652 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 5-1/2 in / 139.7 mm | 94° | ||
| TRJ653 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 2-1/2 in / 63.5 mm | 100° | ||
| TRJ654 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 3-1/8 in / 79.4 mm | 120° | ||
| TRJ655 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 3-1/8 in / 79.4 mm | 106° | ||
| TRJ656 | Single-bend swivelCatalogue dimensions retained; TRJ656 A-inch fraction and metric dimension disagree. Confirm. | A: 2-31/65 in / 66.5 mm; B: 3-7/10 in / 94 mm | 90° | ||
| TRJ657 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 4 in / 101.6 mm | 100° | ||
| TRJ658 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 5-1/2 in / 139.7 mm | 100° | ||
| TRJ659 | Single-bend swivelA and B follow catalogue drawing. | A: 1-44/50 in / 48 mm; B: 3-1/2 in / 89 mm | 90° | ||
| TRJ660 | Single-bend swivelA and B follow catalogue drawing. | A: 1-44/50 in / 48 mm; B: 8-4/5 in / 223 mm | 90° | ||
| TRJ669 | Single-bend swivelA and B follow catalogue drawing. | A: 1-5/64 in / 27.4 mm; B: 2-1/2 in / 63.5 mm | 90° | ||
| J1076C | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 42 mm / 1.654 in (approx.); B-length 73 mm / 2.874 in (approx.) | 90° | ||
| J1175C | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 34.9 mm / 1.374 in (approx.); B-length 104.8 mm / 4.126 in (approx.) | 88° | ||
| J1014A | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 48.4 mm / 1.906 in (approx.) | Not stated | ||
| J1076B | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 32 mm / 1.26 in (approx.); B-length 83 mm / 3.268 in (approx.) | 86° | ||
| J1076D | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 56 mm / 2.205 in (approx.); B-length 59 mm / 2.323 in (approx.) | 90° | ||
| J1076E | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 39 mm / 1.535 in (approx.); B-length 76 mm / 2.992 in (approx.) | 68° | ||
| J1075B | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 36 mm / 1.417 in (approx.); B-length 108 mm / 4.252 in (approx.) | 82° | ||
| J1075C | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 39 mm / 1.535 in (approx.); B-length 105 mm / 4.134 in (approx.) | 88° | ||
| J1078B | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 39 mm / 1.535 in (approx.); B-length 118 mm / 4.646 in (approx.) | 82° | ||
| J1078C | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 39 mm / 1.535 in (approx.); B-length 124 mm / 4.882 in (approx.) | 90° | ||
| J1079B | Screw-on inner tube valveCatalogue image labels include a TR prefix for selected models; table model numbers retained. | A-height 39 mm / 1.535 in (approx.); B-length 133 mm / 5.236 in (approx.) | 88° | ||
| TRSP2 | Tubeless spudCatalogue inch and metric values disagree; 11/16 in equals approx. 17.46 mm. | Height: 11/16 in / 15.8 mm (as printed) | Confirm size |
Dimensions are catalogue values unless labelled as converted. Approximate inch conversions use 25.4 mm per inch. Thread designations remain unchanged. Read configuration notes before ordering.
Include the complete configuration and quantity for each selected model.
Additional Existing Products
These existing items are listed separately from the current catalogue model table.
Frequently Asked Questions
How do I choose the right large-bore tire valves & accessories configuration?
Match the bore system, mounting thread and lettered dimensions. Confirm whether the selected row is a complete valve or an accessory.
What is listed for TRJ650?
Single-bend swivel. A: 1-5/64 in / 27.4 mm; B: 3-1/8 in / 79.4 mm. 100°. A and B follow catalogue drawing.
What should I include in a wholesale quotation request?
Select the required models or configurations and enter quantities. Add your delivery country and packaging requirements. For a repeated catalogue model, include the size, thread or other configuration shown in the table.
