Air Tool Accessories

Flat-Faced Tire Rasps

Flat-faced tire rasps for repair-area preparation, with a 2 in (51 mm) catalogue diameter and two listed widths. Compare four models in 16 or 32 grit, all using a 3/8-24 thread. Choose the flat rasp profile, width and quantity for your wholesale inquiry.

Key Specifications

Models: 93-150 / 93-150A / 93-151 / 93-151A
Catalogue diameter: 2 in (51 mm)
Listed widths: 3/16 / 1/4 in (5 / 6 mm)
SSG grit / mounting: 16 or 32 grit / 3/8-24 thread

* Catalogue entries; confirm final specifications.

Select Models Download Catalogue

Ask about this product

Product Details

This flat-faced rotary rasp series combines two widths with two SSG grit grades. The 93-150 pair lists 3/16 in (5 mm), while the 93-151 pair lists 1/4 in (6 mm). Each pair shares the same 2 in (51 mm) catalogue diameter.

Select the width to match the required working contact, then specify the grit. The A-suffix models use 32 grit; the corresponding models without the suffix use 16 grit. All four models have a 3/8-24 threaded mounting. The flat working profile distinguishes this range from the round-faced 93-153 series.

Model Differences

93-150 / 93-150A: 2 × 3/16 in (51 × 5 mm), with 16 / 32 grit respectively.
93-151 / 93-151A: 2 × 1/4 in (51 × 6 mm), with 16 / 32 grit respectively.
All models: flat-faced profile and 3/8-24 threaded mounting.

Applications

Flat-profile tire preparation

Choose the flat working face where it matches the intended repair procedure. Compare the 5 mm and 6 mm catalogue widths before selecting the model.

Mixed-grit workshop stock

Stock 16 and 32 grit as separate SKUs. The A suffix identifies the 32-grit alternative within each size pair, making repeat orders easier to specify.

Confirm the tool or adapter thread, operating speed and abrasive requirements before use.

Models & Specifications

Dimensions shown in inches and millimeters. Select each model and enter your quantity.

4 models

Swipe the table to compare all dimensions.

Model specifications and quotation quantities
Model / SKU	Type	Size (in)	Size (mm)
93-150	Flat-faced / 16 grit	2 × 3/16	51 × 5
93-150A	Flat-faced / 32 grit	2 × 3/16	51 × 5
93-151	Flat-faced / 16 grit	2 × 1/4	51 × 6
93-151A	Flat-faced / 32 grit	2 × 1/4	51 × 6

Dimensions and SSG grit grades follow catalogue page 39. All models use a 3/8-24 thread. Inch and metric values are catalogue nominal entries; confirm final tolerances for your application.

No models selectedSelect models above to build your inquiry.

Selection checklist: profile and dimensions · tool compatibility · quantity per model

Frequently Asked Questions

How do the two flat rasp widths differ?

The 93-150 / 93-150A pair lists 3/16 in (5 mm), while 93-151 / 93-151A lists 1/4 in (6 mm). Both pairs list a 2 in (51 mm) diameter.

What does the A suffix mean for these flat-faced rasps?

In this series, 93-150A and 93-151A are 32 grit. Models 93-150 and 93-151 are 16 grit. The matching size pair retains the same dimensions and 3/8-24 thread.

Is a flat-faced rotary rasp the same as a hand flat rasp file?

This page covers rotary flat-faced tire rasps with a 3/8-24 threaded mounting. A hand flat rasp file has a different form and mounting method. Use the SKU and tool connection to identify the required product.

How should I specify a wholesale flat rasp order?

List each model and quantity, then confirm the required width and grit grade. Include your tool or adapter specification and packaging needs so AUTOWIN can check the selection and quote the order.
