Tire Changers & Wheel Balancers

Wheel Balancing Machines

BR-96A is a wheel balancer with manual distance and diameter input. The catalogue lists multiple balancing modes and optional centring accessories.

Key Specifications

Series: Wheel Balancing Machines
Listed configurations: 1
Selection: Machine type · Wheel / rim range · Power / performance
Catalogue reference: Tire Service Products, pp. 104

Select Models Download Catalogue

Ask about this product

Product Details

Confirm the actual rim range and required adapters. Compare maximum wheel weight, supply voltage and installation space. The specification table lists the catalogue models and ordering configurations on this page. Include the selected model, configuration and quantity in your quotation request.

Model Differences

BR-96A: Wheel balancer for passenger, motorcycle and light commercial wheels.

Applications

Typical application

Balancing compatible passenger, motorcycle and light-commercial wheels.

Distributor and workshop orders

Specify the model mix and quantity required for your stock range. Include destination and packaging requirements so the quotation can address the intended order.

Models & Specifications

Compare specifications and select the models or size configurations for your quotation.

1 configurations

Swipe the table to compare all dimensions.

Model specifications and quotation quantities
	Model / SKU	Machine type	Wheel / rim range	Power / performance	Quantity (pcs)
	BR-96A	Wheel balancer for passenger, motorcycle and light commercial wheelsCatalogue inch / metric rim dimensions differ; confirm working range. Manual distance/diameter input; optional motorcycle adaptor and centring accessories.	Max. wheel 65 kg; rim diameter 10–24 in / 265–615 mm; width 1.5–20 in / 40–510 mm	110/220 V; 0.2 kW; 220 rpm; 1 g accuracy; measurement 10 s; noise <70 dB; pack 1080 × 800 × 1150 mm / 42.52 × 31.50 × 45.28 in

Dimensions are catalogue values unless labelled as converted. Approximate inch conversions use 25.4 mm per inch. Thread designations remain unchanged. Read configuration notes before ordering.

No models selectedSelect models above to build your inquiry.

Include the complete configuration and quantity for each selected model.

Frequently Asked Questions

How do I choose the right wheel balancing machines configuration?

Confirm the actual rim range and required adapters. Compare maximum wheel weight, supply voltage and installation space.

What is listed for BR-96A?

Wheel balancer for passenger, motorcycle and light commercial wheels. Max. wheel 65 kg; rim diameter 10–24 in / 265–615 mm; width 1.5–20 in / 40–510 mm. 110/220 V; 0.2 kW; 220 rpm; 1 g accuracy; measurement 10 s; noise <70 dB; pack 1080 × 800 × 1150 mm / 42.52 × 31.50 × 45.28 in. Catalogue inch / metric rim dimensions differ; confirm working range. Manual distance/diameter input; optional motorcycle adaptor and centring accessories.

What should I include in a wholesale quotation request?

Select the required models or configurations and enter quantities. Add your delivery country and packaging requirements. For a repeated catalogue model, include the size, thread or other configuration shown in the table.
